Product details

Product Overview

Our products can be customized according to your requirements.

CUZ350

1.C/U/Z width (120~350)mm;
2,.waist height 40-100mm;
3,.plate thickness t (1.5~3.5) mm adjustable;
4. length 2m-12m;
5. palletizing area: length width height: 12m*1m*0.6m;
6. Application of material: Q195\Q235\Q345B Hot-tied strip or hot-tied galvanized strip

CUZ300

1.C/U/Z: web width 120-300mm
2.Flange: 40-100mm
3.Thickness:1-3.0mm
4. Purlin Min length and Max length: 3-9m
5. palletizing area: length width height: 12m*1m*0.6m;
6.Application of material: Q195\Q235\Q345B Hot-tied strip or hot-tied galvanized strip

FEATURES AT A GLANCE
